| Type |
Digital Single Lens Mirrorless camera |
| Recording media |
SD Memory Card / SDHC Memory Card / SDXC Memory Card Slot 1: Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards. Slot 2: Compatible with UHS-I UHS Speed Class 3 standard SDHC/SDXC Memory Cards. |
| Lens mount |
L-Mount |
| IMAGE SENSOR - Type |
35mm full-frame (35.6mm x 23.8mm) CMOS sensor |
| Camera effective pixels / Total pixels |
24.20 megapixels / 25.28 megapixels |
| Aspect ratio / Color filter |
3:2 / Primary color filter |
| Dust reduction system |
Image sensor shift type |
| LATITUDE |
14+ stops (V-Log) |
| Recording file format - Still image |
JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072) |
| 6K PHOTO** / 4K PHOTO** |
6K PHOTO: MP4 (H.265/HEVC, Audio format: AAC (2ch)) 4K PHOTO: MP4 (H.264/MPEG-4 AVC, Audio format: AAC (2ch)) Extracted still images: JPEG (DCF, Exif 2.31) |
| VIEWFINDER - Type |
OLED Live View Finder |
| Pixels |
Approx. 2.36 million dots |
| Field of view / Magnification |
Approx. 100% / Approx. 0.74x with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 3:2 |
| Eye point / Diopter adjustment |
Approx. 20 mm at infinity; -1.0 m-1 / -4.0 - +4.0 (dpt) |
| Eye sensor |
Yes |
| Display speed |
120fps / 60fps |
| Display time lag |
Approx. 0.005sec |
| REAR MONITOR - Type |
TFT LCD monitor with static touch control |
| Monitor size |
Free-angle, 3.0-inch (7.5cm), 3:2 aspect |
| Pixels |
Approx. 1.84 million dots |
| Field of view |
Approx. 100% |
| FOCUS - Type |
Contrast AF system |
| DFD technology |
Yes |
| Focus mode |
AFS (Single) / AFC (Continuous) / MF |
| AF mode |
Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+* / 1-Area* / Pinpoint / Custom 1, 2, 3 (Full area touch is available) (Scalable AF frame size and flexible AF position) *Human/Animal Detection AF can be set ON or OFF.**** |
| AF detective range |
EV -6 - 20 (F1.4, ISO100 equivalent, AFS) |
| AF custom setting |
AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction |
| AF assist lamp |
Yes |
| AF lock |
Set the Fn button in custom menu to AF lock |
| Post Focus / Focus Stacking |
Yes / Yes |
| 6K PHOTO** / 4K PHOTO** - Burst speed |
6K PHOTO: 30 frames/sec 4K PHOTO: 60 frames/sec, 30 frames/sec |
| Exif information |
Yes (Each JPEG image cropped out of the 6K/4K burst file complies with EXIF.) |
| Flash type |
TTL External Flash (sold separately) |
| Flash mode |
Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off *For iA only. |
| Synchronization speed |
Less than 1/250 second *The guide number decreases at 1/250 second. Only when set to M mode or S mode. |
| OSD LANGUAGE |
Japanese, English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Romanian, Netherlandic, Turkish, Portuguese, Finnish, Danish, Swedish, Greek, Russian |
| Microphone |
Stereo, Wind Noise Canceller: OFF / Low* / Standard / High *When attaching DMW-MS2 (sold separately). |
| XLR microphone |
Yes with DMW-XLR1 (sold separately) |
| Yes with DMW-XLR1 (sold separately) |
Bluetooth® v4.2 (Bluetooth Low Energy (BLE)) |
| Battery |
Li-ion Battery Pack (7.2V, 2200mAh, 16Wh) (bundled) USB power supply, USB power charging |
| Battery life (CIPA standard) |
Approx. 440 images (rear monitor), 470 images (LVF), 1,500 images (Power Save LVF mode*) with S-R2060 *Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec. |
| Battery grip |
DMW-BGS5 (sold separately) |
| Dimensions (W x H x D) |
Approx. 132.6 x 97.1 x 81.9 mm / 5.22 x 3.82 x 3.22 inch (excluding protrusions) |
