| Type |
Digital Single Lens Mirrorless camera |
| Recording media |
SD Memory Card / SDHC Memory Card* / SDXC Memory Card* *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards. |
| Lens mount |
Micro Four Thirds mount |
| Type |
Live MOS sensor (17.3 x 13.0 mm) |
| Camera effective pixels / Total pixels |
20.33 megapixels / 21.77 megapixels |
| AR (Anti Reflection) coating |
Yes |
| Aspect ratio / Color filter |
4:3 / Primary color filter |
| Dust reduction system |
Image sensor shift type |
| LATITUDE |
12 stops (V-Log L) |
| Recording file format - Still image |
JPEG (DCF, Exif 2.31), RAW |
| 6K PHOTO (*¹) / 4K PHOTO (*¹) |
6K PHOTO: MP4 (H.265/HEVC, Audio format: AAC (2ch)) 4K PHOTO: MP4 (H.264/MPEG-4 AVC, Audio format: AAC (2ch)) Extracted still images: JPEG (DCF, Exif 2.31) |
| Aspect ratio |
4:3 / 3:2 / 16:9 / 1:1 |
| File size (Pixels) - 4:3 |
5184x3888(L) / 3712x2784(M) / 2624x1968(S) / 4992x3744(6K PHOTO) / 3328x2496(4K PHOTO) |
| File size (Pixels) - 3:2 |
5184x3456(L) / 3712x2480(M) / 2624x1752(S) / 5184x3456(6K PHOTO) / 3504x2336(4K PHOTO) |
| File size (Pixels) - 16:9 |
5184x2920(L) / 3840x2160(M) / 1920x1080(S) / 3840x2160(4K PHOTO) |
| File size (Pixels) - 1:1 |
3888x3888(L) / 2784x2784(M) / 1968x1968(S) / 2880x2880(4K PHOTO) |
| Image quality |
RAW / RAW+Fine / RAW+Standard / Fine / Standard |
| Image area of video |
Full / Pixel by Pixel |
| STREAMING - Protocol |
RTMP / RTMPS |
| Streaming quality - NTSC (59.94Hz) [FHD] 1920x1080 |
59.94p, 16Mbps* / 8Mbps (H.264) *Not selectable when RTMPS is set. 29.97p, 6Mbps / 3Mbps (H.264) |
| Streaming quality - NTSC (59.94Hz) [HD] 1280x720 |
59.94p, 6Mbps (H.264)29.97p, 4Mbps (H.264) |
| Streaming quality - NTSC (59.94Hz) [HD] 1280x720 |
59.94p, 6Mbps (H.264)29.97p, 4Mbps (H.264) |
| Streaming quality - PAL (50.00Hz) [FHD] 1920x1080 |
50.00p, 6Mbps (H.264)25.00p, 4Mbps (H.264) |
| VIEWFINDER - Type |
OLED Live View Finder |
| Pixels |
Approx. 3.68 million dots |
| Field of view / Magnification |
Approx. 100% / Approx. 1.52x / 0.76x (35mm camera equivalent) with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 4:3 |
| Eye point / Diopter adjustment |
Approx. 21 mm at infinity; -1.0 m-1 / -4.0 - +3.0 (dpt) |
| Eye sensor |
Yes |
| Display speed |
120fps / 60fps |
| REAR MONITOR - Type |
TFT LCD monitor with static touch control |
| Monitor size |
Free-angle, 3.0-inch (7.5cm), 3:2 aspect |
| Pixels |
Approx. 1.84 million dots |
| Field of view |
Approx. 100% |
| FOCUS - Type |
Contrast AF system |
| DFD technology |
Yes |
| Focus mode |
AFS (Single) / AFC (Continuous) / MF |
| AF mode |
Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+ / 1-Area / Pinpoint / Custom 1, 2, 3 (Full area touch is available) (Scalable AF frame size and flexible AF position) |
| AF detective range |
EV -4 - 18 (F2.0, ISO100 equivalent, AFS) |
| AF custom setting |
AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction |
| AF assist light |
Yes |
| AF lock |
Set the Fn button in custom menu to AF lock |
| Post Focus / Focus Stacking |
Yes / Yes |
| Focus Ring Control |
Nonlinear / Linear *When a compatible lens is attached |
| Others |
Focus Peaking, 1-Area AF Moving Speed, AF-ON, AF-ON: Near Shift, AF-ON: Far Shift, Focus/Shutter Priority, Focus Switching for Vert/Hor, AF/AE Lock Hold, AF+MF, MF Assist, MF Guide, Focus Ring Lock, Show/Hide AF Mode, AF-Point Scope, Shutter AF, Half Press Release, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, Loop Focus Frame, AFC Start Point (225-Area), Touch Shutter, Touch AF/AE Function, Touch Pad AF, Lens Focus Resume |
